The Light Guide Flexible type(LGR-F) developed by SME is not only an innovative material, but also an innovative manufacturing process. It is different from the light guide strips on the market. SME's LGR-F is formed through extrusion technology, which co-extruded the inner layer with a special acrylic elastomer and the outer layer with fluororesin material coating. Its soft and flexible characteristics make it easier for more designs and difficult shapes. The shape of the cross-section of the light guide can be customized according to requirements. The design flexibility is increased, light guide is not limited in circular shape only.

This product is widely used in automotive interior lighting, shell decoration of home appliances and display lights of industrial parts.

Description

Light Guide Flexible type (LGR-F) Specifications





LGR-F (Flexible type)
Dia.(mm)Length(meter)
2.2500M/roll
3200M/roll
3.5200M/roll
4100M/roll
5100M/roll
6.3100M/roll

Light Guide Flexible type (LGR-F) Features
• Material: special acrylic elastomer inner core, fluorine resin coated outer layer
• High homogeneity, softness, high temperature resistance, can be adapted to the shape of the product without reprocessing
• Light guide method: side light (single or double side)
• True color technology; No visible color shifting
• Bending Radius: 10-12 times the radius
• Temperature resistance: The actual test is -40~+90℃
• Recommended length: Single light source within 1000mm
• Customizable shape



Light Guide Flexible type (LGR-F) Light Effect


Light Guide Flexible type (LGR-F) Application

Customized Acrylic Processing Service
  • Cutting:  Cutting according to the size required by customers, the precision tolerance can reach ±0.5mm
  • Polishing:  Treat the acrylic surface with a diamond polishing machine to make it smooth and translucent.
  • Drilling:  Drilling according to customer's requirements, and it is matched with customer's sample kit.
  • Bending:  Bending according to customer's requirements, heating the acrylic tube, and then bending with jigs.
  • Chamfering:  The edge of the acrylic pipe is chamfered to reduce sharp edges.
  • Printing:  Print patterns, words or images onto the acrylic surface to achieve personalized decorative effects.
  • Laser cutting:  Using high-power laser beams for precise cutting can achieve diverse cutting needs.
  • Assembly:  process and assemble with the accessories required by customers to complete one continuous line service.
Not all acrylic specifications are available for the above services, please inform us of your needs first, SMEACRYLIC will have a professional team to evaluate for you.
